F-150 Fog Lamp Switch and Wire Harness Installed in Maverick - DIY

[notorious beebs]

This is brilliant! Well done, sir

Sponsored



[blackb13]

Nice work! Couldn't you also just ground to the body if you didn't want to mess with the harness near the bumper?



[Vtec87pr1]

Nice work! Couldn't you also just ground to the body if you didn't want to mess with the harness near the bumper?

Ground its not the wires your adding to the bumper conector its power.

I used the same ground for the fog lamps as the sidemarker ground.



[mpc999]

If anyone have any question or would like me to make the wiring for you let me know i will gladly help.

How mush would you charge for making the wiring harness? Thanks



[Ringo]

This is something not on my foreseeable projects but I must say this is one of the best, most complete tutorials I have ever seen!!
Way to bring it! A++



[Ottocycle]

This is great. Thank you very much for your work. It will save all of us a lot of time. Your OEM approach is very nice and definitely the right approach.



[Darnon]

The real question is if its somehow possible to combine the guts for the foglight center button to make it workable with the hybrid and its extra button for the fuel door.



[jsus]

The real question is if its somehow possible to combine the guts for the foglight center button to make it workable with the hybrid and its extra button for the fuel door.

Why not just use the module from an Escape Hybrid with fog lights? It already exists.



[Darnon]

Why not just use the module from an Escape Hybrid with fog lights? It already exists.

Sure, if you don't mind (and assuming the BCM interprets it properly as) your cargo area lights having the Escape's tailgate open icon.

Although I suppose transferring the button face might be easier.



[710-oil-614]

If anyone have any question or would like me to make the wiring for you let me know i will gladly help.

Honestly I'd pay $100-$150 for the wiring and a detailed write up (I know you've got it all there above). The factory switch gear, wiring off the BCM, and the fog light on the dash....well worth it.



[jsus]

Sure, if you don't mind (and assuming the BCM interprets it properly as) your cargo area lights having the Escape's tailgate open icon.

Although I suppose transferring the button face might be easier.

Good point.. I'd have to imagine that's an easier thing to work around, though.

Wouldn't a module from an F-150 PowerBoost with fog lamps be the best option, then? Those have the pressurized fuel tank with electronic release, with the fuel door release button below the cargo area light button.



[Vtec87pr1]

Honestly I'd pay $100-$150 for the wiring and a detailed write up (I know you've got it all there above). The factory switch gear, wiring off the BCM, and the fog light on the dash....well worth it.

I will have to make a part list first . I will probably send a detail instructions for placing the pins on the bcm conector. And probably making the harness separate from the bumper one if it makes it easy for ppl to install. Before anything i need to ask the admins if im allowed too sell stuff here. And once i tested the system fully i will probably start selling the harness. Because in reality all you need its to make a harness since your bcm should have the pins.

Im not sure on hybrid models though simce mine its an XL Ecoboost.



[jsus]

Before anything i need to ask the admins if im allowed too sell stuff here.

That's what the Member Marketplace section is for.



[710-oil-614]

I will have to make a part list first . I will probably send a detail instructions for placing the pins on the bcm conector. And probably making the harness separate from the bumper one if it makes it easy for ppl to install. Before anything i need to ask the admins if im allowed too sell stuff here. And once i tested the system fully i will probably start selling the harness. Because in reality all you need its to make a harness since your bcm should have the pins.

Im not sure on hybrid models though simce mine its an XL Ecoboost.

If all those chips fall into place - I'll be patient zero!

I'll need to come up with something other than your F-150 fogs though as I"ll have the tow hooks with the Tremor but there is plenty of other plastic and spots to work with.



[Vtec87pr1]

Sure, if you don't mind (and assuming the BCM interprets it properly as) your cargo area lights having the Escape's tailgate open icon.

Although I suppose transferring the button face might be easier.

This should work since pins are all the same you should try it and let us know lol i dont have a hybrid to test this and my fuel door its manual
